Pipe and Cable Sizes/Charging
Piping Information
Model: 09 12 18 24
Liquid Line Inch 1/4 1/4 1/4 3/8
Gas Line Inch 3/8 3/8 1/2 5/8
Drain Line Φ mm 16 16 16 16
Max Length M 25 25 30 50
Max Height M 10 10 20 25
Electrical Wiring Information
Model:
09
12 18 24
Mains Outdoor
3x1.5mm² 3x2.5mm²
Interconnecting/Indoor Power
5x1.5mm² 5x2.5mm²
Power Supply Information
Model: 09 12 18 24
Outdoor Ph/A 1/16 1/16 1/16 1/20
Indoor Powered from Outdoor Unit
Refrigerant Charging Information
Model: 09 12 18 24
Pre – Charge Kg 0.5
0.5 1.0 1.6
Charged to M 5
5 5 5
Additional g/m 12
12 12 24
Refrigerant Type
R32
PLEASE NOTE – when using the 4 core wiring method the interconnecting cable for size 24 systems can be
downsized to 1.5mm
