Midea ACE-09HRFN8 IN User Manual

Determine wall hole location
Correct orientation of Mounting Plate
Remove the screw that attaches the
mounting plate to the back of the
indoor unit.
Secure the mounting plate to the wall
with the screws provided. Make sure
that mounting plate is flat against
the wall.
Drill wall hole for connective piping2
Screw
Step 1：
Step 4：
Step 2：
Step 3：
Confirm the mounting plate you own. Determine the
location of the wall hole based on the position of the
mounting plate.The dotted rectangular box above
shows the size of your product.
The size of the wall hole is determined by the connective pipes. When the size of the gas side
connective pipe is 16mm(5/8") or more, the wall hole should be 90mm(3-9/16"). For the size of
connective pipe is less than 16mm(5/8"), the wall hole should be 65mm(2-1/2").
NOTE
: THE WALL HOLE SIZE
11
Φ
Φ
Indoor unit
outline
Indoor unit dimensions:
715mm(28in)x285mm(11.2in)
Indoor unit dimensions:
805mm(31.7in)x285mm(11.2in)
Indoor unit dimensions:
958.3mm(37.7in)x302mm(11.88in)
Indoor unit dimensions:
1037.6mm(40.85in)x324.9mm(12.79in)
Left rear wall
hole 65mm
(2.5in)
Right rear wall
hole 65mm
(2.5in)
Indoor unit
outline
Indoor unit
outline
36mm (1.4in)
47mm (1.85in)
47mm (1.85in)
285mm(11.2in)
45mm(1.7in) 240mm(9.5in)
143mm(5.6in)
Left rear wall
hole 90mm
(3.54in)
Right rear wall
hole 90mm
(3.54in)
55mm (2.16in)
47mm (1.85in)
47mm (1.85in)
264mm(10.4in)
219mm(8.6in)
344mm(13.5in)
299mm(11.8in)
45mm(1.77in)
45mm(1.77in)
458mm(18in)
230mm(9.1in)
246mm(9.7in)
185mm(7.3in)
139mm(5.5in)
411mm(16.2in)
Left rear wall
hole 65mm
(2.5in)
Left rear wall
hole 65mm
(2.5in)
Right rear wall
hole 65mm
(2.5in)
Right rear wall
hole 65mm
(2.5in)
Indoor unit
outline
39mm (1.5in)
47mm (1.85in)
47mm (1.85in)
45mm(1.7in)
107mm(4.2in)
559mm(22in)
Type A Type B
Dierent models have dierent mounting plates.
For the dierent customization requirements, the
shape of the mounting plate may be slightly
dierent. But the installation dimensions are the
same for the same size of indoor unit.
See Type A and Type B for example.
39mm (1.5in)
39mm (1.5in)
47mm (1.85in)
47mm (1.85in)
148mm(5.8in)
45mm(1.7in)
103mm(4.1in)
107mm(4.2in)
130mm(5.1in)
237mm(9.3in)
402mm(15.8in)
55mm (2.16in)
36mm (1.4in)
243mm(9.57in)
100mm(3.9in)
39mm (1.5in)
