Midea BC1150BS

Service Manual_2018-V1.0
18
8. Dismantling of parts
8.1 Parts on the door
Door seal
1)Take the door seal ①out of door liner.
Glass shelf
1)Lift up the glass shelf with a proper force and pull it out
towards yourself.
8.2 Parts inside the refrigerator
Glass shelf
1)Lift up the glass shelf with a proper force and pull it out
towards yourself.
Evaporator in refrigerating chamber
1) Take down screws and gaskets on the evaporator.
2) Remove the welding on inlet and outlet tubes.
Ice tray
