Service Manual_2018-V1.0
19
8.3 Light system
Door light disassembly and assembly
1)Take down the screw on lampshade, Push the
lampshade inner and take it down.
2)Take down the screw on LED light plate then push out
the light.
8.4 Air duct components refrigerating chamber
Air duct components refrigeratingchamber
Air duct components refrigeratingchamber
8.5 Air duct components in freezing chamber and fan motor
Disassembly and installation of Air duct
Disassembly and installation of Air duct
8.6 Evaporator and temperature sensing system
Evaporator in freezing chamber
To Next Page
