Service Manual_2020-V3.0
28
1） The fan is fastened with clasps and can be removed
directly;2）Change the fan, the reverse operation for
assembly
7.5 Air duct components in freezing chamber and fan motor
Air duct components in freezing chamber
All accessories in the freezing chamber should be
dismantled before removing the air duct components.
1） Remove 1 screws on the cover plate of the
freezing air duct using a cross screwdriver.
2） Pull out the connector terminal of the fan motor.
1、 The fan is fastened with clasps and can be removed
directly;Change the fan, the reverse operation for
assembly
