AC Fan Coil Unit Two-pipe Wall-
- 74 -
Heating Capacity
MKG-500-C/ MKG-500-D
EWT ΔT
Indoor temperature (W.B.)
16 18 20 22
TH WF WPD TH WF WPD TH WF WPD TH WF WPD
°C °C kW m
3
/h kPa kW m
3
/h kPa kW m
3
/h kPa kW m
3
/h kPa
40
8 3.63
0.39 13.17 3.18 0.34 10.53 2.74
0.30 8.13 2.29
0.25 6.00
10 3.22 0.28 7.37 2.77 0.24 5.71 2.32 0.20 4.11 1.88 0.16 2.43
12 2.79 0.20 4.13 2.35 0.17 2.68 1.91 0.14 1.54 1.47 0.11 0.98
14 2.39 0.15 1.79 1.94 0.12 1.17 1.49 0.09 0.88 1.02 0.06 0.61
16 1.97 0.11 1.05 1.51 0.08 0.81 1.04 0.06 0.56 0.54 0.03 0.30
45
8 4.72
0.51 20.14 4.28 0.46 16.97 3.84
0.42 14.14 3.39
0.37 11.39
10 4.33 0.37 11.89 3.88 0.34 9.87 3.44 0.30 8.01 2.99 0.26 6.32
12 3.93 0.28 7.45 3.47 0.25 6.05 3.02 0.22 4.78 2.57 0.18 3.51
14
3.50
0.22 4.74 3.04 0.19 3.59 2.60
0.16 2.42 2.16
0.13 1.47
16 3.08 0.17 2.63 2.64 0.14 1.73 2.19 0.12 1.12 1.74 0.09 0.84
50
8 5.82
0.63 28.25 5.38 0.58 24.71 4.93
0.53 21.28 4.48
0.48 17.97
10
5.44
0.47 17.23 4.99 0.43 14.85 4.54
0.39 12.63 4.10
0.35 10.58
12 5.04 0.36 11.08 4.59 0.33 9.43 4.14 0.30 7.91 3.69 0.27 6.51
14
4.63
0.29 7.43 4.18 0.26 6.23 3.72
0.23 5.13 3.27
0.20 4.12
16
4.21
0.23 5.08 3.75 0.20 4.18 3.30
0.18 3.25 2.85
0.15 2.28
55
8 6.93 0.75 37.52 6.47 0.70 33.36 6.02 0.65 29.34 5.58 0.60 25.66
10
6.54
0.56 23.11 6.09 0.52 20.41 5.64
0.49 17.87 5.19
0.45 15.49
12 6.15 0.44 15.30 5.70 0.41 13.35 5.24 0.38 11.59 4.80 0.34 9.94
14 5.76 0.36 10.53 5.30 0.33 9.14 4.85 0.30 7.85 4.40 0.27 6.64
16
5.35
0.29 7.44 4.89 0.26 6.39 4.44
0.24 5.41 3.98
0.21 4.49
60
8 8.03 0.87 47.79 7.57 0.81 42.90 7.12 0.77 38.60 6.67 0.72 34.43
10
7.65
0.66 29.77 7.19 0.62 26.81 6.74
0.58 23.95 6.28
0.54 21.23
12 7.26 0.52 19.89 6.80 0.49 17.76 6.35 0.46 15.83 5.90 0.42 13.93
14 6.87 0.42 13.91 6.41 0.39 12.36 5.96 0.37 10.89 5.50 0.34 9.51
16
6.47
0.35 10.07 6.01 0.32 8.87 5.56
0.30 7.75 5.10
0.28 6.70
Abbreviations:
Δt: Temperature Difference. (℃)
TH: Total Heating Capacity. (kW) WF: Water Flow. (m
3
/h)
WPD: Water Pressure Drop. (kPa)
