II.Dimensions
Installation & Maintenance Manual
CSU-18HCAA CSU-18HHAA CSU-21HCAA CSU-21HHAA
190
5
liquid pipe 6.35 1/4F
gas pipe 12.7 1/2F
external diameter after
heat insulation 35
Four holes
Indoor unit
Mounting board
Porthhole
Mounting board
Air inlet
Air outlet
Drainage pipe
16
external diameter after
heat insulation
28
Power cable
2m to the right side
1m to the left side
Wireless remote controller
unit
CSU-24HCAA CSU-24HHAA indoor unit
