4
2.3 Brief introduction of product structure
2.4 Internal Wire Diagram
(Note:All dimensions are in mm)
15L
A
B
C
D
380
380
312
66
WIRING DIAGRAM
C
A
B
D
E
N
L
Q
Q
Heating Element
Heating Indicator light
Thermal
Cut Out
Thermostat
Power
Indicator
Brown
Blue
Yellow/Green
