Disassemble the bolts from the maintenance board, and pull it in the direction of the arrow
to remove the protection board.
Notice: Do not scratch the surface during operation.
ATTENTION: Chart 23 is based on one type of outdoor units, which may look different
from your own outdoor unit.
Chart 23
Protection
board
Terminator
