5. Electric control system
5.1 Electrical parts parameters
Applicable Model
HC-808WE
Product Model
UL-BCD622WE-DQ
Product code
22031040001581
Rated Voltage
115V 、60Hz
Item
Specification
Specification
Refrigerant
R600a
Compressor
EEI76C13DCH
(Part code : 11101020001422)
Starting device type
DC Inverter
The COP of compressor
2.0 (W/W)
The max cooling capacity of
compressor
255 W
Winding resistance of compressor
wiring terminal (20℃)
U-W:12.4Ω ± 5%
U-V: 12.4Ω ± 5%
W-V: 12.4Ω ± 5%
Winding resistance picture
Starter(PTC)
None
Overload protector(OLP)
None
Integrate PTC+OLP
None
Variable frequency driver board
Have
(Part code : 17131000005241)
Capacitor
None
Power filter (EMI)
250V、4A
Power reactor (EU EMC)
None
Motor
Fan motor of the freezing chamber
DC12V、3.0 W、1600r/min
Fan motor of the refrigerating
chamber
DC12V、3.0 W、1600r/min
Condensation fan motor in
compressor case
DC12V、1.0 W、1150r/min
Fan motor of the ice maker
DC12V、1.5 W、1850r/min
Electric damper
DC12V
Electric damperheater
0.5W
Ice maker motor in refrigerator
DC12V、1.44W
Crushed ice motor
DC120V 55W
