Midea FS40-23MT

PRODUCT INSTALLATION
ASSEMBLY OF CHASSIS & COLUMN UNIT
Installation Procedures
07
2
Insert the column in the chassis and tighten the plastic nut. (If you can’t tighten, check
the nuts on the bottom of the chassis) (Fig.2)
3
From the extension pole loosen the height adjustment ring and adjust the internal pole
to the disired height. (Note:If you can’t find the internal pole, it slides inside the
extension pole. You can pull it out from the extension pole.) (Fig.3)
1
Unpack the packing box and check the parts by referring to the part figure.
From the column unscrew the plastic nut. (Fig.1)
Fig.1
Fig.2
Fig.3
Loose
EN
