08
4
5
To attach the head unit to the column, loosen the thumb screw on the bottom of the
head unit.
Place the head unit on the column and tighten the thumb screw in alignment with the
groove on the internal pole. (Fig.4)
GRILL & FAN BLADE ASSEMBLY
1
Unscrew the spinner clockwise (or take the spinner out from the bag) and the plastic
nut counter clockwise to remove both of them. Fix the rear guard to the motor then
tighten the plastic nut again. (Fig. 5)
Fig.5
Spinner
Tight
Loose
Plastic nut
Fig.4
Mounting hole
Thumb screw
Annular groove
EN
