Insert the blade into shaft, and make sure the rotor shaft pin is fitted into groove of
the blade. Turn the spinner counter clockwise to tighten the blade. (Fig. 6)
3
Fix the front guard and the rear guard with circlip and then tighten the fan guard
locking screw and nut. (Fig. 7)
4
Align the front grill buckle with the top line of the rear grill from top to bottom, after
aligning, look at the schematic from the back.(Fig. 8)
Fig.6
Fig.7
Fig.8
Tight
Slot
Retaining
Pin
Spinner
Blade
