7 Oscillation control
To make the fan oscillate, push down on the oscillation knob located on the top of the
motor housing. To stop the fan from oscillating, pull up the oscillating knob.
Pull-up for static
Pull-down to swing
Clutch Knob
10
5 Press the grill in both hands in sequence, and when it is installed, you will hear a click.
(Fig. 9)
6 Self-locking installation.(Fig. 10)
Fig.9
Fig.10
1 1
2 2
3 3
Pa!
Grill buckle
EN
