Midea HC-702WE - Page 13

13
87 Cross recessed pan head tapping screw
Q215
21
88 Cross recessed hexagon bordered screw
1022, galvanization
6
89 Right top hinge
Hot rolling pickled plate Q235
1
90 Box assembly
Component
1
91 Frequency conversion plate
Component
1
92 Mains filter
Component
1
93 Main control panel
Component
1
94 Main control panel cover
t0.4/ aluminizing zinc plate
1
95 Foam seal
PE foam
1
96 Compensator component
Component
1
97 Back cover of compressor
t0.35/ aluminizing zinc plate
1
98
Y-shape pan head tapping screw
15# carburized surface
galvanizing passivation
4
99 Drain connection
Blow molding PP
2
100 Drain blind joint
Rubber
2
101 Evaporating pan
PP
1
102 Compressor component
Component
1
103 Back cushion blocking of blower fan
NR
3
104 Chilling fan electromotor
Component
1
105 Front cushion blocking of blower fan
NR
3
106 Blower fan box
Antiflaming PP
3
107 Side cushion blocking of blower fan
NR
3
108 Chilling electromotor support
PP
1
109 Chilling fan blade
ABS
1
110 Dry filter
Copper pipe
1
111 Cushion cover of compressor
Rubber
4
112 Back roller
POM
2
113 Caster axle
Cold-rolled plate
2
114 Floor plate of compressor
t1.5 hot zinc plate
1
115 Power line
Component
1
116
Cross recessed countersunk head stainless steel
tapping screw /
4
117
Right middle hinge component
Hot rolling pickled plate
Q235, chrome-plating
1
118 Middle sleeve
POM
2
119
Cross recessed pan head shoulder locking screw
20#, white galvanized
4
120 Leveling adjuster
POM
2
121 Right support of refrigeration slide
ABS
2
