Midea HC-702WE - Page 15

15
157 Feed water pump box
PS
1
158 Outlet pipe of water pump
Silicon rubber
1
159 Built-in water pump for ice maker
Component
1
160 Feed water pump box cover
PS
1
161 Inlet of water pump
Silicon rubber
1
162 Water tank limit buckle
POM
1
163 Ice exploration rod of ice maker
PP
1
164 Ice maker spacing
PS
1
165 Ice maker hanger
PS
1
166 Ice maker hanging button
PS
1
167 Cross recessed pan head tapping screw
Q215
4
168 Right fruit vegetable box component
Component
1
169 Frame of ice maker & ice cube tray
PS
1
170 Twisting ice cube tray
PP
1
171 Frame cover of ice maker & ice cube tray
PS
1
172 Lower refrigeration drawer dog
Modified PP
1
173 Lower refrigeration drawer
Modified PP
1
174 Strengthened iron of lower drawer
Q235
1
175 Separator of lower refrigeration drawer
Modified PP
1
176 Refrigeration drawer synchronous gear
POM
4
177 Refrigeration synchronous gear connecting rod
Q235
2
178 Right refrigeration slide component
Component
2
179 Quick freezing pan
AL
1
180 Separator of upper refrigeration drawer
Modified PP
1
181 Upper refrigeration drawer
Modified PP
1
182 Left refrigeration slide component
Component
1
183 Ice storage box
Transparent PS
1
184 Refrigeration door switch dog
PP
2
185 Left strut member of refrigeration drawer
Q215+anti-corrosion
2
186 Refrigeration lower door seal component
Component
1
187
Preassembly of refrigeration lower door Component 1
188
Ice scoop PP 1
189
Right strut member of refrigeration drawer Q215+anti-corrosion 2
190
Hexagon flange tapping screw \ 12
191
Cross recessed pan head tapping screw Q215 8
