2
UNPACKING AND SET-UP INSTRUCTIONS
OPERATION INSTRUCTIONS
Control Panel Functions
A
B
C
Power Indicator Light
Power and Setting Control
Thermostat Control
IMPORTANT!
Unpack your heater and find the wheel holding plates and butterfly nuts between the fin
assemblies.
1. Make sure the heater is unplugged and the power
and setting control is in the “0”（OFF） position.
2. TURN THE HEATER UPSIDE DOWN.
3. Attach the wheel holding plates onto the heater
as Fig.1 shows. One is fixed between the last
two fins and the other one is fixed next to metal
control box.
4. Insert the butterfly nuts and tighten them securely.
5. TURN THE HEATER UPRIGHT.
Your heater is now ready to use.
Risk of fire – Do not operate heater without wheel assemblies attached.
Operate heater in upright position only (wheels on bottom, controls on top). Any other
position could create a hazardous situation.
Your heater is equipped with a
polarized alternating current line
plug (a plug having one blade
wider than the other). This plug
will fit into the power outlet only
one way. This is a safety
feature. If you are unable to
insert the plug fully into the
outlet, try reversing the plug. If
the plug should still fail to fit,
contact your electrician to
replace your outlet. DO NOT
defeat the safety purpose of the
polarized plug.
A
Cord wrap
Caster Wheels
Fig.1
C
B
