MCAC-KTSM-2009-03 Specifications
Heat Recovery Ventilation 5
Sale Model HRV-500 HRV-800 HRV-1000
Code 220082100210 220082100220 220082100230
Power supply V-Ph-Hz 220V-1Ph-50Hz 220V-1Ph-50Hz 220V-1Ph-50Hz
Temp. efficiency % 60 60 60
Cooling
Enthalpy efficiency % 50 50 50
Temp. efficiency % 70 70 70
Heating
Enthalpy efficiency % 60 60 60
Model YDK60-4D01 YDK-180-4P01 YDK-10-4(992A1)
Insulation class B B B
Safe class IP34 IP34 IP34
Input W 120 360 360
Rated current A 1 2 2.4
Capacitor uF 3.5 8 7
Indoor fan motor
Speed r/min 1250 1350 1150
material ABS ABS ABS
Type Centrifugal fan Centrifugal fan Centrifugal fan
Diameter mm Φ205 Φ246 Φ246
Indoor fan
Height mm 140 203 203
Indoor air flow m
3
/h 500 800 1000
Indoor external static pressure (Hi) Pa 80 100 100
Indoor sound level (sound pressure level) dB(A) 35 39 40
Dimension (W×H×D) mm 824×270×904 1116×388×884 1116×388×1134
Packing (W×H×D) mm 1126×462×1159 1418×580×1139 1418×580×1389
Indoor unit
Net/Gross weight kg 35.5/65.5 57.5/91.5 59/95
Power wiring mm
2
3×2.5 3×2.5 3×2.5
Connection wiring
Signal wiring mm
2
3×0.75 3×0.75 3×0.75
Controller Wired controller (KJR-27B/E)
Fresh Air Diameter mm Φ194 Φ242 Φ242
Fresh air
Air drop (static pressure) Pa 80 100 150
