Specifications MCAC-KTSM-2009-03
4 Heat Recovery Ventilation
4. Specifications
Sale Model HRV-200 HRV-300 HRV-400
Code 220082100180 220082100190 220082100200
Power supply V-Ph-Hz 220V-1Ph-50Hz 220V-1Ph-50Hz 220V-1Ph-50Hz
Temp. efficiency % 60 60 60
Cooling
Enthalpy efficiency % 50 50 50
Temp. efficiency % 65 65 65
Heating
Enthalpy efficiency % 55 55 60
Model YDK-10-4(992A1) YDK20-4A02 YDK40-4C01
Insulation class B B B
Safe class IP34 IP34 IP34
Input W 20 40 80
Rated current A 0.5 0.56 1
Capacitor uF 1.5 1.5 3
Indoor fan motor
Speed r/min 1050 1050 1150
material ABS ABS ABS
Type Centrifugal fan Centrifugal fan Centrifugal fan
Diameter mm Φ146 Φ195 Φ195
Indoor fan
Height mm 104 90 90
Indoor air flow m
3
/h 200 300 400
Indoor external static pressure (Hi) Pa 75 75 80
Indoor sound level (sound pressure level) dB(A) 27 30 32
Dimension (W×H×D) mm 666×264×580 744×270×599 744×270×804
Packing (W×H×D) mm 968×456×835 1046×462×855 1046×462×1059
Indoor unit
Net/Gross weight kg 22/46 23/48 30/57
Power wiring mm
2
3×2.5 3×2.5 3×2.5
Connection wiring
Signal wiring mm
2
3×0.75 3×0.75 3×0.75
Controller Wired controller (KJR-27B/E)
Fresh Air Diameter mm Φ144 Φ144 Φ144
Fresh air
Air drop (static pressure) Pa 75 75 80
