11
Ice Maker
13 Reinstall the freezer shelf and set the ice storage bin on the shelf.
14 Locate the pre-punched holes at the bottom right corner of the back
panel of the refrigerator. Align the bracket of the water valve with the
factory drilled holes, then use a Phillips head screwdriver to drive the
two self-drilling screws through the bracket and into the cabinet.
Ice storage
bin
Water valve
Factory
pre-punched
holes
Self-drilling
screws
To Next Page
