11
Ice Maker
12
Then insert the other end of the long water supply tube directly
into the quick change connector at the bottom of the water valve
and tighten it. After that, place the water valve in accordance with
the drawing and x the water valve iron bracket on the threaded
hole of the side plate of the refrigerator press bin with the green
screws in the accessories. (The water supply tube in the accessories
is quite long, so you can use a knife to cut the water supply tube
to an appropriate length.)
13
The installation of the outside waterway of the ice maker system is
nally completed.
Water
valve
Plastic water
supply tubing
Water tube connector
Fixed pipe clamp
Water value
Water tube
