Specifications
Page 15
Refrigerant piping
Liquid side/ Gas side mm(inch) 2 x Φ6.35/Φ9.52(1/4”/3/8”) 2 x Φ6.35/Φ9.52(1/4”/3/8”) 2 x Φ6.35/Φ9.52(1/4”/3/8”)
Max. length for all rooms m 40 40 40
Max. length for one indoor
unit
m 25 25 25
Max. height difference be-
tween indoor and outdoor unit
m 15 15 15
Max. height difference
between indoor units
m 10 10 10
Ambient tem-
perature
Cooling °C -15~50 -15~50 -15~50
Heating °C -15~24 -15~24 -15~24
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
