FAN mode
Press the "MODE" button until the"FAN " indicator light comes on.
Press the "FAN SPEED" button on the remote controller to choose the fan speed. The temperature can not
be adjusted.
Do not put the duct to window.
4. UP and DOWN buttons
Used to adjust (increasing/decreasing) temperature settings in 1°C/2°F (or 1°F) increments in a range of
16°C/60°F to 30°C/88°F (or 86°F).
NOTE: The control is capable of displaying temperature in degrees Fahrenheit or
degrees Celsius. To convert from one to the other, press and hold the Up and Down
buttons at the same time for 3 seconds.
5. Display
COMFORTSENSE feature (On some models)
This feature can be activated from the remote control ONLY. There is no indicator light on the control panel.
The remote control serves as a remote thermostat allowing for the precise temperature control at its location.
To activate the ComfortSense feature, point the remote control towards the unit and press the ComfortSense
button. The remote control will send this signal to the AC until the ComfortSense button is pressed again.
If the unit does not receive the ComfortSense signal during any 7 minute interval, the unit will exit the
ComfortSense mode.
NOTE: This feature is unavailabe under FAN or DRY mode.
6. Other features
Shows the set temperature while on Cool, or Auto mode. It shows the room temperature on DRY and
FAN modes.
Shows Error codes:
EH00-EEPROM error.
EH60-Room temperature sensor error.
EH61-Evaporator temperature sensor error.
EC52-Condenser temperature sensor error (on some models).
EH0b-Display panel communication error.
EC-Refrigerant leakage detection malfunction(on some models).
Shows protection
code:
P1-Bottom tray is full--Connect the drain hose and drain the collected water away. If protection repeats,
call for service.
NOTE:
and unplug the power cord. Contact the manufacturer, its service agents or a similar
qualified person for service.
18
