Midea MAW08HV1CWT User Manual

3. Place the Unit Into the Window
4. Extend the Side Panels
5. Install the Frame Lock
Keep a fi rm grip on the air conditioner, carefully place the unit into the window opening so the bottom of the
air conditioner frame is against the window sill (Fig. 6A & Fig. 6B). Carefully close the window behind the top
rail of the unit.
Extend the side panels out against the window frame (Fig. 7A for wooden windows), (Fig. 7B for Vinyl-Clad
windows).
Place the frame lock between the frame extensions and the window sill as shown (Fig. 8A for wooden windows),
(Fig. 8B for Vinyl-Clad windows).
INSIDE
OUTSIDE
OUTSIDE
INSIDE
Vinyl-Clad WindowsWooden Windows
Fig. 6A Fig. 6B
Window
frame
The Frame Lock
Fig. 7A Fig. 7B
Wooden Windows
Fig. 8A
Vinyl-Clad Windows
Fig. 8B
16

Midea MAW08HV1CWT Specifications

General

Brand	Midea
Model	MAW08HV1CWT
Category	Heat Pump
Language	English
