Page #37 background image
I&O manual
33
Information requirements for heat pump space heaters and heat pump combination heaters
Model(s):
[yes]
[yes/no]
[yes/no]
[yes/no]
[yes/no]
[yes/no]
tinUeulaVlobmySmetItinUeulaVlobmySmetI
Seasonal coefficient of performance SCOP 3.85 Active mode coef. of performance
SCOP
on
X.XX
Net seasonal coef. of performance
SCOP
net
X.XX
T
j
= – 7 °C
Pdh 27.3 kW
T
j
= – 7 °C
COPd 2.84
T
j
= + 2 °C
Pdh 17.1 kW
T
j
= + 2 °C
COPd 3.60
T
j
= + 7 °C
Pdh 15.4 kW
T
j
= + 7 °C
COPd 5.24
T
j
= + 12 °C
Pdh 12.5 kW
T
j
= + 12 °C
COPd 6.43
T
j
= bivalent temperature
Pdh 27.3 kW
T
j
= bivalent temperature
COPd 2.84
T
j
= operation limit temperature
Pdh 31.5 kW
T
j
= operation limit temperature
COPd 2.40
Bivalent temperature
(maximum +2°C)
Tbiv -7 °C
For air-to-water HP : Operation limit
temperature
(maximum -7°C)
Degradation coefficient
(4)
at T
j
= -7°C
Cdh x,xx
Degradation coefficient
(4)
at T
j
= +2°C
Cdh x,xx
Degradation coefficient
(4)
at T
j
= +7°C
Cdh x,xx
Degradation coefficient
(4)
at T
j
= +12°C
Cdh x,xx
Off mode
P
OFF
0.08 kW
Thermostat-off mode
P
TO
0.40 kW
Standby mode
P
SB
0.08 kW Type of energy input
Crankcase heater mode
P
CK
0.08 kW
etar wolf ria detaR :PH retaw-ot-ria roFelbairav/dexiflortnoc yticapaC
Q
airsource
24000
m
3
/h
Sound power level, indoors
L
WA
x dB(A) For water-to-water: Rated water flow rate
Q
watersource
x
m
3
/h
Sound power level, outdoors
L
WA
84 dB(A) For brine-to-water: Rated brine flow rate
Q
brinesource
x
m
3
/h
Contact details
Name and address of the manufacturer or its authorised representative.
(1) For heat pump space heaters and heat pump combination heaters, the rated heat output Prated is equal to the design load for heating Pdesignh, and the rated
heat output of a supplementary heater Psup is equal to the supplementary capacity for heating sup(Tj).
(2) If Cdh is not determined by measurement then the default degradation coefficient is Cdh = 0,9.
Other items
Outdoor heat exchanger
variable
Power consumption in modes other than active mode Supplementary heater (to be declared even if not provided in the unit)
Rated heat output (3)
Psup
= sup(Tj)
x,x kW
Cycling interval capacity for heating
at Tj
= +12°C
Pcych x,x kW
COPcyc x,xx
Cycling interval efficiency
at T
j
= +12°C
COPcyc x,xx
Cycling interval capacity for heating
at T
j
= +7°C
Pcych x,x kW
Cycling interval efficiency
at T
j
= +7°C
Cycling interval efficiency
at T
j
= +7°C
COPcyc x,xx
Cycling interval capacity for heating
at Tj
= +2°C
Pcych x,x kW
Cycling interval efficiency
at T
j
= +12°C
COPcyc x,xx
x,xx
Cycling interval capacity for heating
at T
j
= -7°C
Pcych x,x kW
Heating water
operating limit temperature
WTOL x °C
For air-to-water heat pumps:
T
j
= – 15 °C (if TOL < – 20 °C)
Pdh x,x kW
For air-to-water heat pumps:
T
j
= – 15 °C (if TOL < – 20 °C)
COPd
Equipped with a supplementary heater:
Heat pump combination heater:
For low-temperature heat pumps, parameters shall be declared for low-temperature application. Otherwise, parameters shall be declared for medium-temperature application.
Parameters shall be declared for average climate conditions.
Rated heat output
(3)
at Tdesignh = -10 (-11) °C
Prated
= Pdesignh
31 kW Seasonal space heating energy efficiency
η
s
152 %
Low-temperature heat pump:
Air-to-water heat pump:
Water-to-water heat pump:
Brine-to-water heat pump:
TOL -10 °C
MC-SU60-RN1L
Table 10-4
