Midea MC-SU60-RN1L Engineering Data

1 Aqua Tempo Super II
201902 13
Part 1 - General Information
Figure 1-5.6: Space heating through floor heating loops and space cooling through fan coil unit (customized unit with built-in hydronic module)
Master unit
Expansion tank
Water replenishment valve
Water discharge valve
Differential pressure
by-pass valve
Drain valve
Two-way valve
Three-way valve
FCU
Auxiliary electric heater
unit
unit
Y-type filter,
requiring≥ 16 mesh
Slave unit
Max 16 units
FCU
FCU
Floor
Heating
Loops
Floor
Heating
Loops
Floor
Heating
Loops
Two-way valve
Two-way
valve
Two-way
valve
One-way
valve
One-way
valve
Stop valve Pressure gauge Gate valveFlexible joint
Y-shaped filter Thermometer Circulating pump Check valve
Automatic discharge valve
Legend

Midea MC-SU60-RN1L Specifications

General

Brand	Midea
Model	MC-SU60-RN1L
Category	Chiller
Language	English
