Midea MCA-48HRN2

18
Chart 35
Power
380V~
50Hz
5-core Cable
2
H07RN 5x2.5mm
5-core Cable
2
H07RN 5x2.5mm
2
1. H07RN 4X1.0mm
1. Cooling/Heating type
2
2. H07RN 3X1.0mm
2. Cooling only type
INDOOR UNIT
123456
1234
ABCN
C1 C B A N
Outdoor unit
NOTE: The cooling only type without the links listed by broken line.
MCA-42(36,48)CRN2
MCA-42(36,48)HRN2
3-core AWG24
air conditioner link-circuit
