Midea MCA-48HRN2

Please check whether the following fittings are of full scope. If there are some attached fittings free
from use, please restore them carefully.
Installation Fittings
Tubing & Fittings
1. Expansible hook..........................................4
2. Installation hook..........................................4
3. Installation paper board...............................1
4. Bolt M5 16 or M6 12.............................4
ATTACHED FITTINGS
5. Connecting pipe group...............................1
7. Soundproof / insulation sheath...................2
6. Binding tape................................................6
8. Out-let pipe sheath.......................................1
9. Out-let pipe clasp.........................................1
10. Tightening band.......................................20
11. Drain elbow.................................................1
12. Seal ring.....................................................1
13. Wall conduit..............................................1
14. Wall conduit cover....................................1
Power/Signal Wiring Group
15. Power wiring of the indoor unit.................1
16. Weak electrical wiring between
the indoor and outdoor units....................1
Drainpipe Fittings Protect Pipe Fittings
Remote controller & Its Frame
Others
21. Owner's manual.......................................1
22. Installation manual...................................1
17. Remote controller......................................1
18. Frame........................................................1
19. Mounting screw(ST2.9 10-C-H) .............2
20. Alkaline dry batteries (AM4)......................2
3
Liquid-side
tubing
MCA-42(36,48)CRN2
MCA-42(36,48)HRN2
gas-side
tubing
f9.53mm f12.7mm
f16mm f19mm
MCA-24CRN2
MCA-24HRN2
