Dimensions
24 Indoor Units
2. Dimensions
H
G
E
F
A
B
D
C
L
M
Capacity
(KBtu)
Outline dimension(mm) Air outlet opening size Air return opening size
Size of outline
dimension mounted
plug
A B C D E F G H I J K L M
12 700 210 635 570 65 493 35 119 595 200 80 740 350
18/24 920 270 635 570 65 713 35 179 815 260 20 960 350
30/36 1140 270 775 710 65 933 35 179 1035 260 20 1180 490
