Midea MCA3-18CRN1-QB5

Dimensions
A6 Duct Type 61
2. Dimensions
Note: standard product without filter Unit: mm
Model
Outline dimension(mm) Air outlet opening size Air return opening size
Size of install
hanger
Size of refrigerant pipe
A B C D E F G H I J K L M H1 H2 W1 W2
18K 880 210 674 600 140 706 50 136 782 190 40 920 508 78 148 88 112
24K~36K 1100 249 774 700 140 926 50 175 1001 228 5 1140 598 80 150 130 155
48K~60K 1200 300 874 800 123 1044 50 227 1101 280 5 1240 697 80 150 185 210
