Midea MCD-24HRN1-Q1 - Page 89

Light Commercial R410A on-off DM17-01.01.08en
89
Indoor Model MUE-36HRN1-R1 MUE-48HRN1-R MUE-60HRN1-R
Outdoor Model MOD31U-36HN1-R MOU-48HN1-R MOUA-60HN1-R
Power supply V-ph-Hz 380~415-3-50 380~415-3-50 380~415-3-50
Cooling
Capacity Btu/h 36000 48000 55000
Input W 3600 5060 6400
Current A 6 8.4 10.5
EER W/W 2,93 2,78 2.52
Heating
Capacity Btu/h 36000 52000 60000
Input W 3650 5063 5800
Current A 6.1 8.6 9.6
COP W/W 2,89 3,01 3.03
Indoor fan
motor
Model YKSS-125-4-5 YSK125-4C YSK85-4C
Qty 1 1 2
Input W 148/131/122 148/131/122 120/110/105
Capacitor uF 4.5 4.5uF/450V-P0 2.5uF/450V
Speed(Hi/Med/Lo) r/min 1370/1300/1225 1370/1300/1225 1315/1200/1120
Indoor coil
Number of rows 2 3 3
Tube pitch(a)x row
pitch(b)
mm
21x13.37
21x13.37 21x13.37
Fin spacing mm 1,3 1,3 1,3
Fin type
Hydrophilic aluminium
Hydrophilic
aluminium
Hydrophilic
aluminium
Tube outside dia.and
type
mm
Ф7,innergroove tube
Φ7,innergroove tube Ф7,innergroove tube
Coil length x height x
width
mm
935x294x26.74
1010x294x40.11 1300x294x40.11
Number of circuits 6 9 10
Indoor air flow(Hi/Med/Lo) m
3
/h 1819/1536/1331 1750/1400/1250 2300/1800/1600
Indoor noise level (sound
pressure)(Hi/Med/Lo)
dB(A) 53.6/50.0/47.1
53/48/44 55/49/46
Throttle type / / /
Indoor unit
Dimension (WxDxH) mm 1285x675x235 1285x675x235 1650x675x235
Packing (WxDxH) mm 1360x755x313 1360x755x313 1725x755x313
Net/Gross weight kg 29.9/35.5 31/36 39/45
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Drainage water pipe diameter mm ODФ25 ODΦ25 ODΦ25
Refrigerant
piping
Liquid side/Gas side mm(inch) Φ9.52/Φ19(3/8"/3/4") Φ12.7/Φ19 Φ12.7/Φ19
Controller RG36C/BG(C)E RG36C/BG(C)E RG36C/BG(C)E
Operation temperature
Ԩ
17~30 17~30 17~30
Room
temperature
Cooling
Ԩ
17～32
17~32 17~32
Heating
Ԩ
0～30
0~30 0~30
