103
9. Disassembly Instructions
Note: This part is for reference, the photos may have slight difference with your machine.
MCH2U-18PHH2 (WCA30 metal plate)
No
.
Part name
Procedures
Remarks
1 Fan
assembly
How to remove the fan
assembly.
1) Turn off the air conditioner
and turn off the power
breaker.
2) Remove the screws of air
outlet grille(4 screws)
3) Remove the hex nut fixing
the fan.
4) Remove the fan.
5) Remove the screws of top
cover, and remove the top
4s
Screws of top
cover
