Midea MDT24H3AST User Manual

13
Safety
Precautions
Operating
Requirements
Parts and
Features
Start Up
Guide
Controls
Dishwasher
Loading
Dishwasher
Use
Dishwasher
Care
Troubleshooting
c OPTIONS
Options enhance the wash cycle. Some Options are available with only
certain Wash Cycles. Refer to the “Cycle and Options Charts” to see
which Options are available for the wash cycle you selected.
•
Press the desired Option control(s). The Option control(s)
illuminates to indicate which option(s) have been selected.
SANITIZE
WARNING: Only sanitizing cycles have been designed to meet the
requirements for soil removal and sanitization efficacy. There is no
intention, either directly or indirectly, that all cycles on a certified
machine have passed the sanitization performance test.
The sanitize option sanitizes dishes and glassware in accordance with
NSF International NSF/ANSI Standard 184 for Residential Dishwashers.
Certified residential dishwashers are not intended for use in licensed
food establishments.
When the Sanitize option is selected, the water temperature will reach
156.2°F (69°C) maximum.
The Sanitize Control illuminates to indicate when the Wash cycle with
the Sanitize option is completed. The light will turn off after the door
has been opened for 30 seconds.
NOTE: It is possible that the water will not reach 156°F (69°C) in the
Sanitize mode, if the temperature of the incoming hot water does not
meet the minimum requirement of 120°F (49°C).
HI TEMP
When the Hi Temp option is selected, the water temperature will be
maintained at 136°F (58°C) maximum during the wash portion of the
cycle.
HEATED DRY
When the Heated Dry option is selected, the heater will work during
the drying process.
EXTENDED DRY
When the Extended Dry option is selected, the heater and fan
operation will be extended to further improve drying performance.
The final rinse will be elevated to 156.2°F (69°C) and extend the Dry by
42 minutes.
d ADDITIONAL FEATURES
DELAY
The Delay Time feature allows you to program the dishwasher to begin
the selected wash cycle 2, 4 or 8 hours later.
Press the DELAY control repeatedly to toggle between (2h / 4h / 8h).
The LED next to the selected time will illuminate.

Midea MDT24H3AST Specifications

General

Style	Free-Standing
Color	Stainless Steel
Load Capacity	14 Place Settings
Number of Cycles	6
Cycle Selections	Heavy
Options/Settings	Smart Control (Wi-Fi App)
Drying Type	Extended Dry (2 Fan Assisted)
Temperature Options	-
Noise level	45 dBA
Special Features	Single Touch Programming
Energy Class	-
Annual Energy Consumption	260 - 270 kWh
Energy Consumption Per Cycle	1.039 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120V
Frequency	60 Hz
Current	-

Weight and Dimensions

Depth	24.5 in
Height	33.8 in
Width	23.9 in
Net Weight	110.3 lbs
