MCAC-VTSM-2016-02 R410a All DC Inverter Mini VRF
Specifications&Performance 13
3. Service Space
Unit: mm
>300
>600
>300
>
2000
(Wall or obstacle)
Maintain
channel
Air outlet
Air inlet
Air inlet
Single unit installation
>600
>2000
>300
Parallel connect the two units or above
>2000 >500 >3000 >3000 >300
Parallel connect the front with rear sides
