Midea MDV-D140Q4/N1-E User Manual

MCAC-VTSM-2017-01 Silent Four-way Cassette
84
Specifications
Model
MDV-D56Q4/N1-E
MDV-D71Q4/N1-E
MDV-D80Q4/N1-E
Power supply
220-240V~ 50Hz
Cooling
Capacity
kW
5.6
7.1
8
Power input
W
88
88
110
Rated current
A
0.41
0.41
0.48
Heating
Capacity
kW
6.3
8
9
Power input
W
88
88
110
Rated current
A
0.41
0.41
0.48
Indoor fan motor
Model
YDK26-6S
YDK30-6S
YDK37-6S
Type
AC
Insulation class
B
Safe class
IP20
Input
W
80
80
100
Output
W
26
30
37
Capacitor
uF
3
3
3.5
Indoor coil
Number of rows
2
Tube pitch(a) × row pitch(b)
mm
21×13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic aluminium
Tube size
mm
Ф7
Tube type
Innergroove tube
Coil length × height × width
mm
2051×168×26.74
Number of circuits
8
Indoor air flow (H/M/L)
m
3
/h
905/740//651
950/767//663
1200/1021/789
Sound pressure level (H/M/L)
dB(A)
36/34/33
38/36/35
42/39/37
Indoor unit body
Net dimension (W×H×D)
mm
840×230×840
Packing size (W×H×D)
mm
955×260×955
Net/Gross weight
kg
23.7/28.9
Indoor unit panel
Net dimension (W×H×D)
mm
950×54.5×950
Packing size (W×H×D)
mm
1035×90×1035
Net/Gross weight
kg
6/9
Refrigerant type
R410A
Throttle type
Electronic expansion valve
Design pressure (H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Φ9.53
Gas pipe
mm
Φ15.9
Drain pipe
mm
Φ32
Controller
Wireless remote controller
Notes:
Capacities are based on the following conditions:
Cooling: Indoor temperature 27°C DB / 19°C WB; Outdoor temperature 35°C DB / 24°C WB.
Heating: Indoor temperature 20°C DB / 15°C WB; Outdoor temperature 7°C DB / 6°C WB.
Piping length: Interconnecting piping length is 7.5m, level difference is 0m.
Sound values are measured in a semi-anechoic room, at a position 1.4m downward from the unit center.

Midea MDV-D140Q4/N1-E Specifications

General

Cooling Capacity	14.0 kW
Refrigerant	R410A
Indoor Unit Type	Ducted
Air Flow (Indoor Unit)	2400 m³/h
Operating Temperature (Heating)	-15°C to 24°C
Power Supply	380-415V/3Ph/50Hz
Outdoor Unit Type	Inverter
Type	Split System
