IPM board,
202302141237
PFC -L2
[1.6]2014.10.16
EU-KFR105W/BP2T3N1-350(767).D.13.MP2-1
PFC-L1
EARTH
+
CN 55
TO-MAIN
W
V
U
IPM2
IPM1
IC1424C08
C N54
L-IN2
N-IN2
OU T FAN(DC)
IC1
CN53
power supply
connect to the terminal
208-230V AC
CN54
CN51CN52
PFC
inductance
terminal
CN58
EATTH
-
+
210-300VDC (Running)
CAPACITOR Voltage
290-330VDC (standby)
CN55
TO MAIN
CN19
connect to DC fan motor
U
V
W
10-200VAC (running)
0VAC (standby)
connect to the compressor
U
V
W
10-200VAC (running)
0VAC (standby)
CN57
Debug
