Service manual for Wash and Dry Combo product
-------------------------------------------------------------------------------------------------------------------------------------------------------
－
－
25 Drawer Handle And Printing 1.0 12138100012090
26 Control Panel Assembly 1.0 12138100020331
27 Cycle Select Knob Assembly 1.0 12138100012972
28 PCB 1.0 17138100016511
29 Water Inlet Valve 1.0 17438000000464
30 Water Inlet Valve 1.0 17438100000415
31 Basket Assembly 1.0 12238100000513
32 Tub Water Inlet Hose Assembly 1.0 12638100000278
33 Front Tub Assembly 1.0 12138100020335
34 Door Gasket Clamp 1.0 12938100000018
35 Door Gasket 1.0 12638100000523
36 Counterweight Assembly 1.0 12738100000268
37 Damper 4.0 12938100000466
38 Damper Pin 8.0 12138100002987
39 Internal Wire Assembly 1.0 17438100004325
40 Three phase asynchronous motor 1.0 11002013003115
41 Bearing 1.0 12938100000132
42 Bearing 1.0 12938100000137
43 Shaft_seal 1.0 12638100000288
44 Upper Counterweight 1.0 12338100000198
45 Suspension Spring 2.0 12900104000018
46 Belt 1.0 12638100000421
47 Pulley 1.0 12338100000281
48 Rear Tub Assembly 1.0 12138100020341
49 Heater 1.0 17438100000435
50 Tub Drain Hose Assembly 1.0 12638100000488
51 Tunnel Assembly 1.0 12338100001621
51.1 Temperature Sensor 2.0 17438100001351
51.2 Thermostate 2.0 17400513000457
51.3 Condenser Assembly 1.0 12138100020343
51.4 Tunnel Base Assembly 1.0 12338100000748
51.5 Heater 1.0 17438100004245
51.6 Tunnel Cover Assembly 1.0 12338100000746
51.7 Fan Flange Assembly 1.0 17438100000707
