Service manual for Wash and Dry Combo product
-------------------------------------------------------------------------------------------------------------------------------------------------------
－
－
7. SPARE PARTS
No. Part Name Quantity BOM Code
1 Top Cover Assembly 1.0 12138100020340
2 Rear Cover 1.0 12238100002053
3 Power Cord 1.0 17438100001072
4 Shipping Screw Assembly 4.0 12938100000062
5 Drain Hose Assembly 1.0 12138100010151
6 Capacitor Assembly 1.0 17438100001082
7 Water Level Sensor 1.0 17438100001348
8 Door Lock 1.0 17438100004745
9
Permanent magnet synchronous
pump 1.0 11001011001329
10 Felt 1.0 12238100005463
12 Front Panel Assembly 1.0 12238100001021
12.1 Service Plate Box 1.0 12138100003574
12.2 Front Panel 1.0 12238100005781
12.3 Door Hinge Assemble Bracket 1.0 12238100003382
13 Door Gasket Spring Clip Spring 1.0 12938100000049
14 Fireproofing Plate 1.0 12238200002276
15 Cabinet Assembly 1.0 12238100003461
16 Front Panel Pin 2.0 12138100018556
17 Top Bracket 1.0 12238100000028
18 Spring Support 2.0 12138100003060
19 Capacitor Assembly 1.0 17438100001082
20 Water Inlet Hose Assembly 1.0 12038100000543
21 Electric Filter Assembly 1.0 17438100001354
22 Door Subassembly 1.0 12138100019639
22.1 Door Glass 1.0 12538100000005
22.2 Inner Ring 1.0 12138100005230
22.3 Outer Frame Assembly 1.0 12138100002020
22.4 Hinge Assembly 1.0 12338100000185
22.5 Door Plunger 1.0 12338100000215
23 Dispenser Subassembly 1.0 12138100020338
24 Drawer Assembly 1.0 12138100009673
