Floor Standing MFM DM16-01.01.25en
Service manual 10
MOU‐48HN1‐RB6W MOUL‐60HN1‐R
LIQUID SIDE
GAS SIDE
HEAT
EXCHANGE
(EVAPORATOR)
HEAT
EXCHANGE
(CONDENSER)
Compressor
2-WAY VALVE
3-WAY VALVE
4-WAY VALVE
COOLING
HEATING
T2 Evaporator
temp. sensor
T1 Room temp.
sensor
T3 Condenser
temp. sensor
T5 Discharge temp. sensor
T4 Ambient
temp. sensor
INDOOR OUTDOOR
Oil return Capillary
Oil separator
Low pressure
switch
High pressure switch
CHECK VALVE
(Heating Model only)
CAPILIARY TUBE
