Midea MFM-48ARN1-R User Manual

DM16-01.01.25en Floor Standing MFM
5 Service manual
2 .Specifications
Model MFM-24ARN1-Q MFM-48ARN1-R MFM-60ARN1-R
Outdoor MOF-24HN1-QB8 MOU-48HN1-RB6W MOUL-60HN1-R
Power supply V-ph-Hz 220-240-1-50 380-415-3-50 380-3-50
Cooling
Capacity
Btu/h 24500 47900 57900
kW 7,18 14,04 16,97
Input W 2700 5150 6500
Rated current A 13 9.0 11.0
EER W/W 2.66 2.73 2.61
Heating
Capacity
Btu/h 27500+7500 52000+12000 62000+12000
kW 8.06+2.20 15.24+3.52 18.17+3.52
Input W 2500+2200 5350+3700 5300+3700
Rated current A 12+10 9.2+5.3 10.0+5.3
COP W/W 3.22 2,85 3,43
Max. input consumption W 3500+2200 5800+3700 8200+3700
Max. current A 16.6+10 10.5+5.3 14.7+5.3
Starting current A 66 66 67
Compressor
Model PA290G2CS-4MU1 C-SBN373H8D C-SBN453H8D
Type ROTARY SCROLL SCROLL
Brand GMCC PANASONIC PANASONIC
Capacity Btu/h 24771/24959 48109 55957/69264
Input W 2430/2600 4750 5750/6750
Rated current(RLA) A 11.65/12.6 8.22 9.77/9.84
Locked rotor Amp(LRA) A 66 66 67
Thermal protector ----- ---- ----
Thermal protector position INTERNAL INTERNAL INTERNAL
Capacitor uF 50 - - - -
Refrigerant oil/oil charge ml
ESTER OIL
VG74/850
FV68S / 1700 FV68S/1700
Indoor fan
motor
Model YDK75-8 YDK120-8T YDK160-8
Input W 166/145 288/276 347/308
Capacitor uF 5.0 6.5 9.0
Speed(Hi/Mi/Lo)or (Hi/Lo) r/min 540/440 550 / 480 615 / 530
Indoor coil
a.Number of rows 2 2 3
b.Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37 25.4x22
c.Fin spacing mm 1.3 1.4 1.5
d.Fin type (code)
Hydrophilic
aluminium
Hydrophilic
aluminium
Hydrophilic
aluminium
e.Tube outside dia.and type mm Φ7,innergroove tube Φ7,innergroove tube
Φ9.52,innergroove
tube
f.Coil length x height x width mm 405x735x26.74 422x966x26.74 484x812x66
g.Number of circuits 6 10 6
Indoor air flow (Hi/Lo) m3/h 1100/900 1700/1480 2250/1950
