Floor Standing MFM DM16-01.01.25en
Service manual 6
Indoor noise level (Hi/Lo) dB(A) 47/43 52/49 54/51
Indoor unit
Dimension(W*D*H) mm 500x315x1700 550x418x1824 600x455x1934
Packing (W*D*H) mm 1805x615x425 1935x655x540 2040x745x595
Net/Gross weight Kg 38.6 / 50 55.8 / 70 68.5/88.3
Outdoor fan
motor
Model YDK53-6C YDK65-6F(B) x2 YDK65-6F(B) x2
Input W 136 162 162
Capacitor uF 3.0 3.5 3.5
Speed r/min 800 765 765
Outdoor coil
a.Number of rows 2 2 2
b.Tube pitch(a)x row pitch(b) mm 22x19.05 22x19.05 22x19.05
c.Fin spacing mm 1.4 1.6 1.6
d.Fin type (code) Hydrophilic aluminium
e.Tube outside dia.and type mm
Φ7.94,innergroove
tube
Φ7.94,innergroove
tube
Φ7.94,innergroove
tube
f.Coil length x height x width mm 770x660x38.1 837x1100x38.1 837x1100x38.1
g.Number of circuits 4 8 8
Outdoor noise level dB(A) 60 64 64
Outdoor unit
Dimension(W*D*H) mm 845x320x700 900x350x1170 900x350x1170
Packing (W*D*H) mm 965x395x755 1032x443x1307 1032x443x1307
Net/Gross weight Kg 50 / 53.3 97 / 107 96 / 107
Refrigerant type g R410A/1800g R410A/3300g R410A/3200g
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch)
Φ9.52/Φ15.9(3/8"/5/
8")
Φ12.7/Φ19(1/2"/3/4"
)
Φ12.7/Φ19(1/2"/3/4"
)
Max. refrigerant pipe length m 20 20 20
Max. difference in level m 10 10 10
Connection wiring mm
2
2.5(Optional) 2.5(Optional) 2.5(Optional)
Plug type - - - - - -
Operation temperature
Ԩ
17-30 17-30 17-30
Room
temperature
Indoor(cooling/ heating)
Ԩ
17-32/0-30 17-32/0-30 17-32/0-30
Outdoor(cooling/heating)
Ԩ
18-43/-7-24 18-43/-7-24 18-43/-7-24
Application area m
2
33-48 64-94 77-113
