Midea MGA-D16/SN1

R410A Mini Split Chiller 50Hz MCAC-ATSM-2014-01
20
Model
MGA-D14/SN1
Ta. (°C)
Tw (°C)
5
6
7
8
9
10
25
Pf (kW)
14.8
15.1
15.4
15.7
16.1
16.4
Pa (kW)
3.6
3.6
3.6
3.7
3.7
3.7
Pat (kW)
4.1
4.1
4.1
4.2
4.2
4.2
Qev (m
3
/h)
2.6
2.6
2.7
2.7
2.8
2.8
△Pev (kPa)
49.3
50.0
51.7
53.0
56.1
57.8
30
Pf (kW)
14.1
14.4
14.7
15.0
15.3
15.6
Pa (kW)
4.1
4.1
4.1
4.2
4.2
4.2
Pat (kW)
4.6
4.6
4.7
4.7
4.7
4.7
Qev (m
3
/h)
2.4
2.5
2.5
2.6
2.6
2.7
△Pev (kPa)
43.9
47.9
48.3
49.1
50.2
52.7
35
Pf (kW)
13.4
13.7
14.0
14.3
14.6
14.9
Pa (kW)
4.6
4.6
4.6
4.7
4.7
4.7
Pat (kW)
5.1
5.1
5.1
5.2
5.2
5.2
Qev (m
3
/h)
2.3
2.4
2.4
2.5
2.5
2.5
△Pev (kPa)
40.8
43.5
44.2
46.9
47.8
48.3
40
Pf (kW)
12.5
12.8
13.1
13.4
13.7
14.0
Pa (kW)
5.1
5.1
5.1
5.2
5.2
5.2
Pat (kW)
5.6
5.6
5.6
5.7
5.7
5.7
Qev (m
3
/h)
2.2
2.2
2.3
2.3
2.4
2.4
△Pev (kPa)
33.3
34.5
36.7
39.8
43.7
44.9
43
Pf (kW)
12.0
12.3
12.6
12.9
13.2
13.5
Pa (kW)
5.5
5.5
5.5
5.6
5.6
5.6
Pat (kW)
6.0
6.0
6.0
6.1
6.1
6.1
Qev (m
3
/h)
2.1
2.1
2.2
2.2
2.3
2.3
△Pev (kPa)
30.6
32.5
35.2
36.2
39.1
40.5
Remark:
Ta: outside air temperature (°C )
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m
3
/h)
△ Pev: evaporator pressure drop (kPa)
