Midea MGA-D16/SN1

R410A Mini Split Chiller 50Hz MCAC-ATSM-2014-01
22
12.2 Heating capacity
Model
MGA-D10/N1
Ta. U.R.87% (°C)
Tw (°C)
35
40
45
50
-5
Pt (kW)
8.3
8.3
8.3
—
Pa (kW)
3.6
3.9
4.2
—
Pat (kW)
4.4
4.7
5.0
—
Qc (m
3
/h)
1.5
1.5
1.5
—
△ Pc (kPa)
29.4
28.4
27.0
—
0
Pt (kW)
9.4
9.4
9.4
9.2
Pa (kW)
3.7
4.0
4.3
4.5
Pat (kW)
4.5
4.8
5.1
5.3
Qc (m
3
/h)
1.8
1.8
1.8
1.8
△ Pc (kPa)
27.5
25.6
24.8
23.2
7
Pt (kW)
13.2
13.1
13.0
12.9
Pa (kW)
3.8
4.1
4.4
4.7
Pat (kW)
4.6
4.9
5.2
5.5
Qc (m
3
/h)
2.2
2.2
2.2
2.2
△ Pc (kPa)
37.2
35.8
34.5
33.1
10
Pt (kW)
12.3
12.2
12.1
12.0
Pa (kW)
3.9
4.2
4.5
4.8
Pat (kW)
4.7
5.0
5.3
5.1
Qc (m
3
/h)
2.3
2.3
2.3
2.3
△ Pc (kPa)
40.5
40.0
39.2
38.8
15
Pt (kW)
13.8
13.7
13.6
13.5
Pa (kW)
4.0
4.3
4.6
4.9
Pat (kW)
4.8
5.1
5.4
5.7
Qc (m
3
/h)
2.4
2.4
2.3
2.3
△ Pc (kPa)
45.8
45.1
43.6
42.9
Remark:
Ta: outside air temperature (°C )
Tw : evaporator water outlet temperature (°C)
Pt: heating capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qc: condenser water flow (m
3
/h)
ΔPc: evaporator pressure drop (kPa)
— : conditions outside of operating limits
