Midea MGA-D16/SN1 User Manual

MCAC-ATSM-2014-01 R410A Mini Split Chiller 50Hz
37
No.
Part Name
Quantity
No.
Part Name
Quantity
1
Top cover ass'y
1
11.1
4-way valve
1
2
Accumulator cylinder
1
11.2
4-Ways valve solenoid
1
3
Condenser ass'y
1
11.3
Low pressure valve
1
4
Valve plate
1
12
Compressor
1
5
Front clapboard ass'y
1
13
Base
1
6
E-part box ass'y
1
14
Compressor electric heater
1
6.1
AC contactor
1
15
Discharge pipe ass'y
1
6.2
Surge suppresser
1
15.1
Pressure controller
1
6.3
Main control board ass'y
1
16
Suction pipe ass'y
1
6.4
Transformer
1
16.1
Pressure controller
1
6.5
Wire joint
1
16.2
Pressure-relief-valve
1
6.6
Motor capacitor
2
17
Motor bracket ass'y
1
6.7
Wire joint, 3p
1
18
Grille
2
6.8
Wire joint
1
19
Motor
2
6.9
Electric installation board ass'y
1
20
Wired controller
1
6.10
Cable
1
21
Axial flow fan
2
6.11
Outdoor communication cable
1
22
Motor bracket ass'y
1
6.12
Wire joint
3
23
Rear support board I
1
6.13
Wire joint
1
24
Rear net clip
1
6.14
Wire joint, 5p
1
25
Front panel
1
7
Urgency switch
1
26
Discharge temp. sensor ass'y
1
8
Rear clapboard ass'y
1
27
Temp. sensor ass'y
1
9
Handle
2
28
Discharge temp. sensor
1
10
High pressure valve ass'y
1
29
Room temp. sensor ass'y
1
10.1
Low pressure valve
1
30
Fixing ring
1
11
4-way valve ass'y
1
31
Rear support board II
1
Water pump box CE-SBX/SN1-01A
No.
Part Name
Quantity
No.
Part Name
Quantity
1
Up covering plate
1
18.2
Branch pipe
2
2
Water-inlet pipe ass'y
1
18.3
Screw
1
2.1
Pipe joint
1
18.4
Elbow pipe
1
2.2
Elbow pipe
1
18.5
Inner joint
1
3
Hook
4
19
Water charge valve
1
4
Pipe clamp I
1
20
Rear clapboard
2
5
Front clapboard
1
21
Input pipe ass'y
1
6
Pipe clamp II
1
21.1
Pipe joint
1
7
Right cover ass'y
1
21.2
Copper nut
1
8
Capacitor clamp
1
22
Water-outlet pipe ass'y
1
9
Water-inlet pipe supporter
2
22.1
Water-outlet pipe ass'y I
1
10
Input pipe ass'y
1
22.2
Drain pipe adapter
1
10.1
Accumulator tank
1
23
Water-outlet pipe ass'y II
1
11
Water-inlet pipe ass'y
1
23.1
Elbow pipe
1
11.1
outer joint
1
23.2
Water-outlet pipe II
1
11.2
Pipe joint
1
23.3
Pipe joint
1
11.3
Water-inlet pipe ass'y I
1
24
Pump
1
12
Base
1
25
Water-outlet pipe ass'y I
1
13
Expansion vessel
1
25.1
Pipe joint
3
14
Heat-exchanger plate ass'y
1
25.2
Elbow pipe
2
14.1
Plate Heat-exchanger
1
26
Installation bracket
1
14.2
Elbow pipe
1
27
Big handle
1
14.3
Pipe joint
1
28
Left clapboard ass'y
1
14.4
Pipe hoop
1
29
Safety valve
1
14.5
Pipe joint
1
30
Discharge valve
1
14.6
Copper nut
1
31
Water-outlet pipe III
1
15
Target flow-volume controller
1
32
Input pipe ass'y
1
16
Clamp
1
32.1
Accumulator tank
1
17
Water charge pipe
1
33
Temp. sensor ass'y
1
18
Water-inlet pipe ass'y II
1
34
Wire joint, 5p
1
18.1
Pipe joint
3
