MCAC-ATSM-2014-01 R410A Mini Split Chiller 50Hz
9
Net/ Gross weight
kg
109/115
122/128
Water pump box
Model
CE-SBX/N1-01
CE-SBX/N1-01A
Code
220095700030
220095700010
Net dimension (W×H×D)
mm
905×370×366
905×370×366
Packing dimension (W×H×D)
mm
1057×439×436
1057×439×436
Net/ Gross weight
kg
54/59
54/59
Refrigerant
Type
R410A
R410A
Charged volume
kg
2.7
3.6
Refrigerant pipe diameter
Liquid side
mm
Φ9.53
Φ9.53
Gas side
mm
Φ19
Φ19
Pipe diameter
Water inlet/outlet
mm
DN32
DN32
Controller
Wired controller KJRM-120D/BMK-E
Ambient temperature
℃
Cooling: 10℃~43℃
Cooling: 10℃~43℃
Heating: -15℃~24℃
Heating: -15℃~24℃
Note:
The specification is based on the following conditions:
1. Cooling mode：ambient temperature 35℃，water inlet/outlet 12/7℃；
2. Heating mode：ambient temperature 7℃，water inlet/outlet 40/45℃；
3. The maximum and minimum operating pressure values refer to the activation of the pressure switches
4. It is tested 1m away in front of the unit in a semi-anechoic room(sound pressure).
