MCAC-2008-11 Air-cooled Modular Chiller
26
No. Part Name Quantity No. Part Name Quantity
1 Top cover 2 24 Base ass'y 2
2 Axial flow fan 2 25 Strengthen bracket 8
3 Motor 2 26 Compressor 4
4 Beam 1 27 Accumulator cylinder 4
5 Suction pipe ass'y B 2 28 Base bracket 1
5.1 Pressure controller 1 29 Base bracket 1
6 Suction pipe ass'y A 2 30 Clamp 2
6.1 Pressure controller 2 31 Holder for Plate Heat-exchanger 2
7 4-way valve ass'y 2 32 E-part box ass'y 2
7.1 Muffler 1 32.1 Main controller ass'y 2
7.2 4-way valve 1 32.2 Wire joint 8
7.3 Pipe joint 3 32.3 Wire joint 2
7.4 Strainer 1 32.4 Wire joint 2
7.5 Pressure controller 1 32.5 Transformer 2
7.6 EEV solenoid 1 32.6 Relay 4
7.7 Discharge temp sensor 1 32.7 Contactor 4
8 4-way valve ass'y 1 32.8 Compressor capacitor 2
8.1 Muffler 1 32.9 E-part box 2
8.2 4-way valve 1 33 Bracket ass'y 2
8.3 Pipe joint 1 34 Base ass'y 1
8.4 Strainer 1 35 Bracket ass'y 2
8.5 Pressure controller 1 36 Drainage pan holder 4
8.6 EEV solenoid 1 37 Connecting pipe ass'y 1
8.7 Discharge temp sensor 1 38 Connecting pipe 1
9 4-way valve ass'y 1 39 4-way valve connection pipe 1
9.1 EEV solenoid 1 40 Heat-exchanger plate 1
9.2 Strainer 1 40.1 Plate Heat-exchanger 1
9.3 Pressure controller 1 41 Heat-exchanger ass'y 1
9.4 Muffler 1 41.1 Electronic expansion valve 2
9.5 4-way valve 1 41.2 Strainer 2
9.6 Pipe joint 3 41.3 Plate Heat-exchanger 1
10 Clapboard supporting board 6 42 Middle partition plate 1
11 Motor bracket 4 43 Sealed board 1
12 Drainage pan 2 44 Water Inlet/Outlet pipe ass'y 1
13 Cover board 4 45 Holder ring 4
14 Side board 2 46 Side sealed board 4
15 Compressor cover bracket 2 47 Cover 2
16 Cover 2 48 Front cover 1
17 4-way valve connection pipe ass'y 1 49 Top cover 1
18 4-way valve connection pipe ass'y 1 50 Support board 4
19 Connecting pipe ass'y 1 51 Rear—front net 4
20 Connecting pipe ass'y 1 52 Sealed board ass'y 2
21 Protecting water box 2 53 Cover 4
22 Rear cover 1 54 Sealed board ass'y 1
23 E-Part box cover 2 55 Sealed board ass'y 1
