MCAC-2008-11 Air-cooled Modular Chiller
9
For digital scroll heat pump 30kW module:
MGA-D( )W/SN1
Model
30 60 90 120 150 180 210 240
Combination (Main module + auxiliary module) Pieces 1+0 1+1 1+2 1+3 1+4 1+5 1+6 1+7
Cooling Capacity kW 30 60 90 120 150 180 210 240
Heating Capacity kW 32 64 96 128 160 192 224 256
Power supply V/Ph/Hz 380-415/3/50
Type Scroll (1 digital scroll plus 1 fixed speed)
Compressor
Quantities Pieces 2 4 6 8 10 12 14 16
Cooling kW 10 20 30 40 50 60 70 80
Power input
Heating kW 9.8 19.5 29.3 39 48.8 58.5 68.3 78
Type R410A R410A R410A R410A R410A R410A R410A R410A
Refrigerant
Weight kg 7 7×2 7×3 7×4 7×5 7×6 7×7 7×8
Air side heat-exchanger type Copper-fin-coil
Quantities of fan motor Pieces 1 2 3 4 5 6 7 8
Air flow volume ×10
3
m
3
/h 12 24 36 48 60 72 84 96
Condenser
(Air side)
Fan motor input kW 0.7 0.7×2 0.7×3 0.7×4 0.7×5 0.7×6 0.7×7 0.7×8
Water side heat-exchanger type Plate type
Water resistance loss kPa 18 18 18 18 18 18 18 18
Water inlet/outlet pipeline diameter mm 133 133 133 133 133 133 133 133
Water flow volume m
3
/h 5.2 10.3 15.5 20.6 25.8 30.9 36 41.2
Max. Pressure MPa 1 1 1 1 1 1 1 1
Evaporator
(Water side)
Water pipe connection type Soft connection
L mm 1514 1514 1514 1514 1514 1514 1514 1514
W mm 850 2300 3750 5200 6650 8100 9550 11000
Dimension
H mm 1820 1820 1820 1820 1820 1820 1820 1820
Packing
size
L×W×H mm 1620×1034×2041
Net weight kg 440 880 1320 1760 2200 2640 3080 3520
Weight
Operating weight kg 470 940 1410 1880 2350 2820 3290 3760
Power wiring mm
2
×No. 10×5-core Connection
wiring
Signal wiring mm
2
×No. 0.75×3-core
Control type Wired controller
Safety protection device
High/low-pressure switch, anti-frost protection, water-flow switch, over-load
protection, and power phases sequence protection.
Power supply V/Ph/Hz 380/3/50 Electric
heater
(optional)
Power input W 7.5 15 22.5 30 37.5 45 52.5 60
Noise level dB(A) 58
Operation water temp ℃ Cooling：5～17 Heating：45～50
Ambient temp ℃ Cooling：17～48 Heating：-10～21
Note: Please refer to the water flow volume in the above table strictly to design and install.
