Midea MGB-D30W/RN1

Air-cooled modular chiller unit 50Hz MCAC-ATSM-2011-12
18
Weight
Net weight kg 600 1150
1730
Operation weight kg 670 1270
2000
Power wire mm
2
×No. 25×4+16×1 35×3+16×2 75×3+35 ×2
Signal wire mm
2
×No. 0.75×3-core 0.75×3-core
Control type Wired controller Wired controller
Safety protection device
1) Protection for over-high discharge
pressure.
2) Protection for over-low suction
pressure.
3) Power supply phase sequence
protection.
4) Anti-frozen protection in cooling
mode.
5) Anti-frozen protection in Winter.
6) Protection for compressor over
current.
7) Protection for compressor
overload.
8) Outlet and inlet water
temperature difference protection.
9) Compressor discharge temp.
protection.
10) Water flow cut-off protection.
11)Sensor malfunction protection.
12)Low ambient temperature
drive-up protection
13)Low-temperature protection of
shell-and-tube heat exchanger.
1) Protection for over-high discharge
pressure.
2) Protection for over-low suction
pressure.
3) Power supply phase sequence
protection.
4) Anti-frozen protection in cooling
mode.
5) Anti-frozen protection in Winter.
6) Protection for compressor over
current.
7) Protection for compressor overload.
8) Outlet and inlet water temperature
difference protection.
9) Compressor discharge temp.
protection.
10) Water flow cut-off protection.
11) Sensor malfunction protection.
Noise level(semi-anechoic ) dB(A) 67 70 74
Operation water temp ℃
Cooling：0～17(0℃ must add
antifreeze)
Heating：22～50
Cooling：5～17 Heating：45～50
Ambient temp ℃ Cooling：10～46 Heating：-10～21 Cooling：10～46 Heating：-10～21
Note: Please refer to the water flow volume in the above table strictly to design and install.
All the above data is measured base on the following working condition:
1. cooling mode under normal working condition: water flow 0.172 m
3
/(h•kW), outlet water temperature of chilled water is
7℃,air inlet temperature of condenser is 35℃;
2. heating mode under normal working condition: water flow 0.172 m
3
/(h•kW), outlet water temperature of chilled water is
45℃,air inlet temperature of condenser is DB/WB 7/6℃.
