MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
75
No. Part Name Quantity No. Part Name Quantity
1
Rear—front net
2 24 underpan parts 1
2 Condenser right seal board ass'y 1 25 underpan bracket 1
3 Double-pipe heat exchanger 1 26 Reinforcement bracket 6
4 Condenser right seal board ass'y 1 27 E-part box ass'y 1
5 Input pipe ass'y of B unit 1 27.1 Main control board ass'y 1
5.1 Electronic expansion valve 1 27.2 Relay 2
6 Input pipe ass'y of A unit 1 27.3 Contactor 1
6.1 Filter 1 27.4 Contactor 1
7 Input pipe ass'y of A unit 1 27.5 Transformer 1
7.1 Electronic expansion valve 1 27.6 Wire joint 2
8 Output pipe ass'y of B unit 1 27.7 Wire joint 1
8.1 Pressure controller 1 27.8 Wire joint 4
9 Output pipe ass'y of A unit 1 27.9 Wire joint 1
9.1 Pressure controller 1 27.10 Comp capacitor 1
10 4-Way valve ass'y of A unit 1 28 Drainage pan bracket 2
10.1 4-Way valve 1 29 E-part box cover board 1
10.2 4-Way valve solenoid 1 30 Drainage pan 1
10.3 Muffler 1 31 Prevent water box 1
10.4 Filter 1 32 Condenser of A unit 1
10.5 Pipe joint 1 33
Rear－below cover board
1
10.6 Pressure controller 1 34 Condenser left seal board ass'y 2
11 Input pipe ass'y of B unit 1 35 Condenser of B unit 1
11.1 Filter 1 36 Motor bracket 2
12 4-Way valve ass'y of B unit 1 37 Side seal board 4
12.1 4-Way valve 1 38 Side bracket 2
12.2 4-Way valve solenoid 1 39 Motor bracket 2
12.3 Muffler 1 40
Rear－front cover board
2
12.4 Filter 1 41 Motor 1
12.5 Pipe joint 1 42 Axial flow fan 1
12.6 Pressure controller 1 43 Top cover 1
13 Suction pipe ass'y of A unit 1 44 Partition board 1
13.1 Pressure controller 1 45 Top cover 1
14 Suction pipe ass'y of A unit 1 46 Seal partition board 1
14.1 Pressure controller 1 47 Rear cover board 1
15 Rear-below and front below bracket 2 48
Rear－front cover board
1
16 front-below cover board 1 49
Left－right side board
2
17 comp cover board 2 50 R410a 7Kg
18 Small underpan bracket ass'y 2 51 EEV solenoid 2
19 Small underpan bracket ass'y 2 52 Ambient temp sensor 1
20 Small underpan 1 53 Discharge temp controller 2
21 Separator 2 54 Comp electric heater 2
22 Compressor 2 55 Pipe sensor 6
23 underpan bracket 1 56 Pipe sensor wire 3
