Midea MGB-D65W/RN1

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
95
No. Part Name
Qty BOM code No. Part Name Qty BOM code
19.3
Electrical component mounting
plate II
1 201290100389 55
Enter the evaporator tube
assembly
1 201690191314
19.4
Main control board ass'y
3 201390100009 55.1
Electronic expansion valve
1 201601300018
19.5
Relay
6 202300800003 56
I output tube condenser
3 201690101358
19.6 AC contactor 6 202300830520 57
Output tube condenser (C
drive) transition tube
assemblies
1 201690101405
19.7 Transformer 3 202300900109 58
Condenser output tube (D
drive) transition tube
assemblies
1 201690101408
19.8
Wire joint, 5p
1 202301450037 59
Shell and tube evaporator
1 201790190020
19.9
Wire joint
10 202301450122 60
Duct I
1 201290100392
19.10
Wire joint
1 202301450130 61
I cover trunking
1 201290100391
19.11
Compressor capacitor
6 202401000410 62
I panel fasteners
10 201290100373
19.12
Three-phase power protection
devices
3 202301600518 63 I fixed plate tube 4 201290100356
19.13 A Terminal Block 3 202301400231 64
Four-way valve assembly II
3 201690191310
19.14
A Terminal Block
1 202301400232 64.1
4-way valve
1 201600600110
20
Seal plate condenser
6 201290100382 64.2
Pressure controller
1 202301800843
21
Components of the
compressor back to the
trachea
5 201690191311 64.3 Pipe joint 2 201601200004
21.1
Pressure controller
1 202301800845 65 separator 6 201601100072
22
I return to the trachea
compressor components
1 201690191330 66 The beams in the 2 201290100385
22.1
Pressure controller
1 202301800845 67 Front Panel 4 201290100368
23
Condenser inlet pipe II
3 201690101354 68 Strengthen the beam I 4 201290100371
24
I enter the tube condenser
components
3 201690101362 69 Network Rail fixed plate I 4 201290100350
25
Part B condenser
3 201590100022 70
Front grille
6 201290100348
26
B fixed plate with pieces of
condenser
3 201290108635 71
Welding parts mounting base
compressors
6 201290100351
27
Axial flow fan
6 201200300013 72
Compressor
6 201402300130
28 Motor 5 202400400399 73
Enter the evaporator tube
assembly
1 201690191317
29
Induction motor
1 202400400564 73.1
Electronic expansion valve
1 201601300018
30
Motor bracket bonding parts
12 201290100375 74
I fixed plate throttle parts
2 201290100358
31
A fixed plate with pieces of
condenser
3 201290108634 75
Enter the evaporator tube
assembly
1 201690191315
32
A machine Condenser Parts
3 201590100021 75.1
Electronic expansion valve
1 201601300018
33 Tube fixed plate II 2 201290100355 76
Enter the evaporator tube
assembly
1 201690191316
34
Welding parts water tray
3 201290100398 76.1
Electronic expansion valve
1 201601300018
35
In lane bridge II
2 201290100352 77
Target flow-volume controller
1 202301820013
36 Tube fixed plate III 12 201290100354 78
Total water temperature
mouth components
1 201690101220
37
Evaporator tube assembly
output
1 201690191318 79 Wired controller 1 203355100210
37.1 Pressure controller 1 202301800842 80 Coil temp sensor ass'y 9 202301300081
38
Evaporator tube assembly
output
1 201690191319 81 Coil temp sensor ass'y 6 202301300400
38.1 Pressure controller 1 202301800842 82
Pipe temperature sensor
assemblies
1 202301300097
39
Evaporator tube assembly
output
1 201690191320 83 Room temp sensor ass'y T41 3 202301300403
39.1 Pressure controller 1 202301800842 84
Discharge temperature
controller
6 202301610049
40 I four-way valve assembly 1 201690191309 85
Electrical heating belt
compression
6 202403100066
40.1 4-way valve 1 201600600110 86
Electronic expansion valve
coil
6 201601300544
40.2
Pressure controller
1 202301800843 87
Four-way valve coil
4 201600600239
40.3
Pipe joint
2 201601200004 88
Four-way valve coil
2 201600600235
41
Four-way valve assembly III
2 201690191325 89
R410A
42 200500100003
